Model noMenClature
Nomenclature
Note: Text displayed in Bold-Italics designate standard offering.
Category Code Item Code Option Code Designation & Description (Bold-Italic = Standard)
Product Category 01 1 W = Water Source Heat Pump
Product Identier 02 2-4 WXH = Slope Top Wall Mtd/High Sill/DDC Less Board/Chassis Only
WXL = Flat Top Wall Mtd/High Sill/DDC Less Board/Chassis Only
WXM = Flat Top Wall Mtd/Low Sill/DDC Less Board/Chassis Only
WXN = Flat Top Wall Mtd/High Sill/DDC Less Board
WXP = Flat Top Wall Mtd/Low Sill/DDC Less Board
WXR = Slope Top Wall Mtd/High Sill/DDC Less Board
WXT = Slope Top Wall Mtd/Low Sill/DDC Less Board/Chassis Only
WXV = Slope Top Wall Mtd/Low Sill/DDC Less Board
WZB = Flat Top Wall Mtd/Low Sill/Mark IV
WZJ = Flat Top Wall Mtd/High Sill/Mark IV
WZN = Slope Top Wall Mtd/Low Sill/Mark IV
WZU = Slope Top Wall Mtd/High Sill/Mark IV/Chassis Only
WZV = Slope Top Wall Mtd/Low Sill/Mark IV/Chassis Only
WZW = Flat Top Wall Mtd/High Sill/Mark IV/Chassis Only
WZX = Flat Top Wall Mtd/Low Sill/Mark IV/Chassis Only
WZY = Slope Top Wall Mtd/High Sill/Mark IV
Design Series (Vintage) 03 5 2 = Design Series 2
3 = Design Series 3
Nominal Capacity 04 6-8 009 = 9,000 Btuh Nominal Cooling
012 = 12,000 Btuh Nominal Cooling
015 = 15,000 Btuh Nominal Cooling
019 = 19,000 Btuh Nominal Cooling
Voltage 05 9 A = 115-60-1 (Size 009 and 012 only)
E = 208-230/60/1
J = 265/277-60-1 (Size 009 and 015 only)
Coil Options 06 10 G = Cupro-Nickel Coax Coil, Geothermal
S = Copper-Steel Coax Coil
T = Cupro-Nickel Coax Coil
W = Copper-Steel Coax, Geothermal
Heating Options 07 11-12 00 = None
(Not available in 115/60/1 voltage) 20 = 1.0 kW Electric Heat Nominal
30 = 2.0 kW Electric Heat Nominal
Note: See Table 7 on page 14 for allowable maximum kW based on
voltage selection
Hand Orientation 08 13 U = Right
V = Left
Controls 09 14-15 11 = Unit-Mounted ACO
12 = Unit-Mounted MCO
13 = 24V Wall T-Stat Setup
*Note: Code 00 designed for use with 25 = Unit-Mounted ACO with Low Limit, NSB and Override
eld-installed Alerton control board 00 = None (DDC Less Control)*
Discharge 10 16-17 AA = Top
Return Air 11 18-19 13 = Front (Low sill only)
14 = Bottom (High sill only)
Power Connection 12 20 A = Std. Electrical Junction Box
C = Cord (Chassis Only)
P = Power Cord w/Fused Disconnect
(Available with cabinet and chassis combination)
Color 13 21 B = Putty Beige (Flat-top only)
C = Cupola White (Slope-top and Flat-top)
G = Soft Gray (Flat-top only)
I = AntiqueIvory(Standardcolorforslope-top,optionforat-top)
Z = None
IM 447-11 4 www.DaikinApplied.com
