Daikin WAA - Product Identifiers; Physical Data

Product Identiers
Previous
Model
Replacement
Model
Cabinet Subbase Height Controls
Chassis
Only
2
Slope Top Flat Top High Sill Low Sill Mark IV
1
DDC Less Board
WAH, WDD, WDN WXH ● ● ● ●
WDC, WDZ, WXG WXL ● ● ● ●
– WXM ● ● ● ●
WAF, WAX, WDF, WDG, WDL,
WDU, WDX, WXC, WXF, WXJ,
WXQ, WZK, WZK
WXN ● ● ●
WAA, WDA, WXE WXP ● ● ●
WAG, WAS, WDH, WDS, WDY,
WZC, WZD, WZG, WZH, WST,
WDS
WXR ● ● ●
WDE WXT ● ● ● ●
WDB, WDJ, WXA, WXB, WZL WXV ● ● ●
WCB, WLB, WMB, WMJ, WMW,
WXD, WXU
WZB ● ● ●
WFQ, WLL, WME, WMF, WMX,
WXS, WZF, WZP
WZJ ● ● ●
WLC, WMA, WMP,
WSQ, WZA
WZN ● ● ●
WMG, WMN, WZQ WZU ● ● ● ●
WCQ, WMH, WMM, WXK, WZZ WZV ● ● ● ●
WMC, WMK, WMT, WMU, WZM WZW ● ● ● ●
WMD, WML, WMQ, WMV, WZE WZX ● ● ● ●
WLA, WLZ, WMO, WMR, WMS,
WMY, WMZ, WZS
WZY ● ● ●
1
Field-supplied control board
2
Subbase not included
Physical Data
Table 1: Physical Data
Unit Size 009 012 015 019
Fan Wheel - D x W (in.) 5-3⁄4 x 9.15 5-3⁄4 x 9.15 6 x 7.8 6 x 7.8
Fan Motor (hp) 1/24 1/15 1/8 1/8
Coil Face Area (ft.
2
) 1.4 1.4 1.9 1.9
Coil Rows 3 3 3 3
Refrigerant Charge (oz.) 21.5 21.5 33.0 33.5
Filter Size (in.) 9-3⁄4 x 23-3⁄4 9-3⁄4 x 23-3⁄4 9-3⁄4 x 31-3⁄4 9-3⁄4 x 31-3⁄4
Water Connections, Tube (in.) 5/8 O.D. 5/8 O.D. 5/8 O.D. 5/8 O.D.
Condensate Connection, I.D. (In.)* 3/4 3/4 3/4 3/4
Weight, Operating (lbs.)
Cabinet & Chassis 164 166 185 193
Chassis Only 125 127 129 131
Weight, Shipping (lbs.)
Cabinet & Chassis 184 186 215 223
Chassis Only 145 146 153 156
* Condensate hoses are 14″ long.
www.DaikinApplied.com 5 IM 447-11
