www.DaikinApplied.com 27 IOM 1274-3 • CENTRIFUGAL WATER CHILLERS
Table 8: Centrifugal Single Compressor Knockdown Dimensions
Label
079/087 087 100
E2612/C2212 E2612/C2612 E3012/C2612 E3012/C3012 E3612/C3012 E3612/C3612 E3612/C3012
DD 35.9 (912.) 40.9 (1039) 40.9 (1039) 44.9 (1141) 43.9 (1115) 50.9 (1293) 43.9 (1115)
EE 49.0 (1245) 51.5 (1308) 56.2 (1429) 59.8 (1520) 77.0 (1955) 83.0 (2108) 77.0 (1955)
FF 52.8 (1245) 58.4 (1308) 63.3 (1429) 67.6 (1520) 69.4 (1955) 78.4 (2108) 65.7 (1955)
GG 35.9 (913.) 37.9 (963.) 40.4 (1026) 44.2 (1124) 43.2 (1099) 50.2 (1275) 43.2 (1099)
HH 30.6 (777.) 36.2 (921.) 36.2 (921.) 42.3 (1075) 42.3 (1075) 46.5 (1183) 40.7 (1034)
JJ 33.3 (846.) 33.3 (846.) 38.4 (976.) 38.4 (976.) 44.4 (1127) 44.4 (1127) 44.8 (1138)
37.0 (941.) 37.0 (941.) 42.4 (1077) 42.4 (1077) 48.4 (1230) 48.4 (1230) 48.4 (1230)
LL 23.8 (604.) 29.4 (747.) 29.1 (739.) 33.4 (848.) 28.7 (731.) 37.7 (959.) 24.6 (625.)
MM 49.9 (1269) 52.4 (1332) 56.2 (1429) 59.8 (1520) 77.0 (1955) 83.0 (2108) 80.6 (2049)
NN 53.5 (1360) 59.1 (1503) 56.2 (1429) 59.8 (1520) 77.0 (1955) 83.0 (2108) 77.0 (1955)
PP 34.0 (865.) 34.0 (865.) 38.4 (976.) 38.4 (976.) 44.4 (1127) 44.4 (1127) 44.8 (1138)
QQ 38.0 (965.) 38.0 (965.) 42.4 (1077) 42.4 (1077) 48.4 (1230) 48.4 (1230) 52.1 (1324)
Label
100/113/126
E3612/C3612 E4212/C3612 E4216/C3616 E4212/C4212 E4216/C4216
DD 50.9 (1293) 50.9 (1293) 50.9 (1293) 57.9 (1471) 57.9 (1471)
EE 83.0 (2108) 89 (2260) 89.0 (2260) 95 (2413) 95 (2413)
FF 65.7 (2108) 71.0 (2260) 71.0 (2260) 73.1 (2413) 73.1 (2413)
GG 50.2 (1275) 50.2 (1275) 50.2 (1275) 56.9 (1446) 56.9 (1446)
HH 45.3 (1152) 45.3 (1152) 45.3 (1152) 49.5 (1259) 49.5 (1259)
JJ 44.8 (1138) 52.4 (1331) 52.4 (1331) 52.4 (1331) 52.4 (1331)
48.4 (1230) 54.4 (1382) 54.4 (1382) 54.4 (1382) 54.4 (1382)
LL 24.6 (625.) 21.7 (553.) 21.7 (553.) 23.9 (607.) 23.9 (607.)
MM 86.6 (2201) 91.9 (2334) 91.9 (2334) 97.9 (2486) 97.9 (2486)
NN 65.7 (1670) 71.0 (1803) 71.0 (1803) 73.1 (1858) 73.1 (1858)
PP 44.8 (1138) 52.4 (1331) 52.4 (1331) 52.4 (1331) 52.4 (1331)
QQ 52.1 (1324) 57.1 (1452) 57.1 (1452) 57.1 (1452) 57.1 (1452)
Table 9: Vessel Component Weights
Vessel Dry Weight 2 Pass Standard Waterbox Marine Waterboxes Dished Return Head
lbs kg lbs kg lbs kg lbs kg
E2612 3880 1760 143 65 985 447 75 34
E3012 4669 2118 245 111 1400 635 132 60
E3612 6769 3070 328 149 2238 1015 131 59
E4212 8922 4047 450 204 3176 1441 210 95
E4216 11591 5258 450 204 3176 1441 210 95
E4816 14888 6753 648 294 4471 2028 269 122
C2212 3071 1393 167 76 704 319 54 24
C2612 5010 2272 185 84 1032 468 75 34
C3012 7210 3270 300 136 1454 660 132 60
C3612 9801 4446 329 149 2290 1039 131 59
C3616 13118 5950 329 149 2290 1039 131 59
C4212 10267 4657 531 241 3358 1523 210 95
C4216 17845 8094 531 241 3358 1523 210 95
