Air Conditioner Service Manual
77
4. Remove the electric control box cover
Unfix one screw on the cover of electric
box, and remove the cover.
Push the filter upwards a little, you can
take it out from unit.
6. Disassembly the middle frame.
A. Open the screw cover, and unfix
screw with cross screwdriver.
B. Remove the middle frame by
loosing the clasps with the unit
base as shown in the picture and
take the frame out.
To Next Page
