Daitsu DS-9KIDR - Page 84

Air Conditioner Service Manual
84
step10：Disassemble the compressor.
Unscrew the nuts
and take the
compressor out.
step11：Remove the fan motor and fan supporter.
Unfix screws btw fan
motor with
supporter, and
supporter with base
plate.
Note:
Pay attention to the
motor wiring, it can’t
be taken out by
force.
