Dake SE712 - Parts List

Dake Corporation
724 Robbins Road
Grand Haven, MI 49417
www.dakecorp.com
21 REV022019
PARTS LIST
Item
Part No.
Ref No.
Part Name
Qty
1
300935
181107-2
Swivel Base
1
2
300757
181108A
Acme Screw
1
3
300907
W002
Washer (1/2”)
1
4 300860 S601
Hex. Socket Headless Screw
(1/4"-20 x 1/2")
1
5
300758
181606
Wheel-hand
1
6
300752
3027-1
Handle
1
7
301269
181266
Fixed Bolt
1
8
43633
W008
Flat washer (3/8”)
2
9
300936
181114
Vise Jaw Bracket (Front)
1
10
300937
HP021
Pin (Ø5 x 35mm )
1
11
300938
181136A
Bracket
1
12
300755
181604
Acme Nut
1
13
300909
181605
Button
1
14
300910
W203
Spring Washer (3/16”)
2
15
300911
191206
Spring Retainer
1
16 78833 HS519
Cross Round Head Screw
(M5 x 10mm)
1
17 43331 S410
Hex. Socket Head Screw
(3/8”-16 x 1-1/2”)
1
18
43916
N001
Hex. Nut (1/2”-13)
1
19
300907
W002
Washer (1/2”)
2
20
302492
S501
Carriage Screw (1/2”-12 x 2”)
1
21
302491
S003
Hex. Head Screw (1/2”-12 x 2”)
1
22
300939
181113-1
Vise Jaw Bracket (Rear)
1
23
300940
181121
Bushing
1
24
300941
181122-1
Support Rod
1
25
43314
S022
Hex. Head Screw (5/16”-18 x 3/4")
1
26
300942
181123
Pivot Bracket
1
27
301296
181270
Retaining Plate
1
28
43331
S012
Hex. Head Screw (3/8”-16 x 1-1/2”)
2
29
301686
181133
Support Plate
1
30
-
181134
Fixed Plate
1
31
300943
181117-1
Spring or 301290
1
32
301291
181118
Spring Adjusting Screw
1
33
301687
181115
Spring Handle Bracket
1
34
43314
S022
Hex. Head Screw (5/16”-18 x 3/4")
1
35
43632
W016
Flat Washer (5/16”)
1
36
43912
N005
Hex. Nut (3/8”-16)
1
37
43633
W014
Flat Washer (3/8”)
1
38
301688
181130
Thumb Screw
1
39
43314
S022
Hex. Head Screw (5/16"-18 x 3/4")
1
40
300944
3021
Stock Stop Rod
1
