Dake SE712 - Page 27

Dake Corporation
724 Robbins Road
Grand Haven, MI 49417
www.dakecorp.com
26 REV022019
Item
Part No.
Ref No.
Part Name
Qty
293
43301
S006
Hex. Head Screw (1/4-20 x 1/2”)
2
294
43631
W004
Washer (1/4”)
2
295
300957
K008
Key (5mm x 5mm x 30mm)
1
296 301451 S604
Hex. Socket Headless Screw
(M6-1.0 x 6mm)
1
297
300959
181235
Motor Pulley
1
298
70320
S503
Carriage Screw (5/16” x 1”)
4
299
43330
S013
Hex. Head Screw (3/8”-16 x 1-1/4”)
1
300
300741
M301
Motor 12.5 amps
1
301374
-
Motor Fan
1
301375
-
Motor Cover
1
301
43319
S021
Hex. Head Screw (5/16-18 x 2”)
2
302
43911
N007
Hex. Nut (5/16”-18)
2
303
301708
181234A
Motor Mount Plate
1
304
43911
N007
Hex. Nut (5/16”-18)
4
305
43314
S022
Hex. Head Screw (5/16”-18 x 3/4”)
4
306
43632
W016
Flat Washer (5/16”)
8
307
301709
181233A
Motor Mount Bracket
1
310 301484 S201
Cross Round Head Screw
(1/4”-20 x 1/2”)
2
311
43631
W005
Washer (1/4”)
2
312
301802
181232-1
Support Plate
1
313
301486
3055-3
Vertical Saw Table
1
314
43633
W008
Flat washer (3/8”)
3
316
301289
Scale
1
317
302952
3149
Vent Plug (M8 x P1)
1
318
301766
3072-2
Bearing Cover
1
319 - S302
Flat Cross Head Screw
(3/16”-24 x 3/8”)
3
320
301710
181245
Bushing
1
326 43881 S708
Cross Round Head Screw
(#10-24 x 3/8”)
2
330
-
181980
Fitting (3/8” x 5/16” PT)
1
330-1
-
181602
Pipe Jointer (Ø6mm)
1
330-2
-
181603
Pipe Nut (10mm)
1
333
43627
W007
Washer (3/16”)
2
335
-
Wire Nipple (5/8”)
1
339
-
181992
Bushing
1
340
-
181993
Cylinder Protector
1
341
301299
181301-2
Cylinder Lower Support
1
342
301191
181302-2
Cylinder Upper Support
1
343
43631
W005
Flat Washer (1/4”) (For CE Only)
1
344
N/A
181988
Gear Box Protector (For CE Only)
1
345 N/A 181991
Emergency Switch Bracket
(For CE Only)
