Piranha Color Camera User’s Manual 11
DALSA 03-032-10211-01 5/9/2007
-10 dB 0 dB +10 dB
Notes
Operating
Specification
Unit
Min Typ Max Min Typ Max Min Typ Max
FPN (FCC
disabled)
DN
pk to pk
1 18
PRNU ECD DN
pix to pix
350 350
PRNU ECE DN rms
pix to pix
20 350 350 725
PRNU DN
pk to pk
180
PRNU
Corrected
ECD
ECE
DN
DN
608
608
608
608
854
NEE pJ/cm
2
SEE nJ/cm
2
Optical Interface Units Value Notes
Back Focal Distance
M72 Mount
mm
91.56 (M72 x 0.75)
Sensor Alignment
x
y
z
0z
μm
μm
μm
°
±50
±50
±250
Lens Mount
Mechanical Interface Units Value Notes
Camera Size mm (l x h x w) 67 x 105 x 76
Mass g
Connectors
power connector
data connector
Electrical Interface Units Notes
Input Voltage Volts +12 to +15
Power Dissipation W 12
Operating
Temperature (front
plate)
°C 0 to 50
Data Output Format Bits
Output Data
Configuration
To Next Page
