Piranha Color Camera User’s Manual 7
DALSA 03-032-10211-01 5/9/2007
1
1
Features and Specifications
1.0 Introduction
Camera Features
2048 or 4096 trilinear RGB line scan sensor
Color spacing: 3 lines, center to center
Forward and reverse scanning operation
Maximum line rates of 22 kHz (2k60) and 32 kHz (2k80), or 12 kHz (4k60) and 17 kHz
(4k80).
Programmable analog gain and offset
FPN and PRNU correction
White balancing algorithms
Optional luminance output
Spatial correction
Anti-blooming
Configurable Base or Medium Camera Link
Applications
100% print inspection
Electronics manufacturing inspection
Postal/parcel sorting
High performance document scanning/image lift
Narrow and large web inspection
High-end industrial inspection
Models
PC-30-02k60: 2k resolution, 3 taps at 60 MHz
PC-30-04k60: 4k resolution, 3 taps at 60 MHz
PC-30-02k80: 2k resolution, 3 taps at 80 MHz
PC-30-04k80: 4k resolution, 3 taps at 80 MHz
