Piranha Color Camera User’s Manual 25
DALSA 03-032-10211-01 5/9/2007
Example:
scb 75
3.5 Help
For quick help, the camera can return all available commands and parameters through
the serial interface.
There are two different help screens available. One lists all of the available commands to
configure camera operation. The other help screen lists all of the commands available
for retrieving camera parameters (these are called “get” commands).
To view the help screen listing all of the camera configuration commands, use the
command:
Syntax:
h
To view a help screen listing all of the “get” commands, use the command:
Syntax:
gh
Notes: For more information on the camera’s “get” commands, refer to
section
Returning Camera Settings.
The camera configuration command help screen lists all commands available. Parameter
ranges displayed are the extreme ranges available. Depending on the current camera
operating conditions, you may not be able to obtain these values. If this occurs, values
are clipped and the camera returns a warning message.
Some commands may not be available in your current operating mode. The help screen
displays NA in this case.
The following help screen listing are for a 2k camera:
ccf correction calibrate fpn
ccg calibrate camera gain iti 1-4:0-0:1024-4055
ccp correction calibrate prnu
cil calibrate input lut
clm camera link mode m 5/9/10/14/15/16/
cpa calibrate PRNU algorithm mi 1/2/3/4/:1024-4055
css correction set sample m 1024/2048/4096/
dil display input lut taa 0-0:0-1023:0-1023
dpc display pixel coeffs xx 1-2048:1-2048
ebc enable blue correction i 0-1
eil enable input lut i 0-1
els end of line sequence i 0-2
epc enable pixel coefficients ii 0-1:0-1
gcl get command log
gcm get camera model
gcp get camera parameters
gcs get camera serial
gcv get camera version
get get values s
gfc get fpn coeff x NA
gh get help
gil get input lut ta NA
gl get line xx 1-2048:1-2048
gla get line average xx 1-2048:1-2048
gpc get prnu coeff x NA
