Piranha Color Camera User’s Manual 52
DALSA 03-032-10211-01 5/9/2007
3.18 Saving, Loading and Restoring Settings
Saving and Restoring Settings
Figure 8: Saving and Restoring Overview
Current
Settings
LUT
FPN
PRNU
Factory
Settings
LUT
FPN
PRNU
User
Settings
LUT
FPN
PRNU
PC
Settings
LUT
FPN
PRNU
L
F
S
User
Settings
LUT
FPN
PRNU
User
Settings
LUT
FPN
PRNU
User
Settings
LUT
FPN
PRNU
WUS
WIL
WFC
WPC
LUS
LIL
LFC
LPC
SSN 0
SSN 1-4
SSN 5
Factory Settings
On first initialization, the camera operates using user set 1, which has been set equal to
the factory settings. You can restore the original factory settings at any time using the
command lfs.
User Settings
You can save or restore your user settings to non-volatile memory using the following
commands. Pixel coefficients and LUTS are stored separately from other data.
To save all current user settings to Flash, use the command wus. The camera will
automatically restore the saved user settings when powered up. Note: While
settings are being written to nonvolatile memory, do not power down the camera or
the camera's memory may be corrupted.
To load the user settings from non-volatile memory, use the command lus.
To write and load the LUTs, use the wil and lil commands, respectively.
