Piranha Color Camera User’s Manual 21
DALSA 03-032-10211-01 5/9/2007
Medium Configuration Timing
Medium Configuration
Connector 1 Connector 2 Maximum SSF
8
kHz
CLM
1
Bits
2
Taps
3
Lum
4
Port
6
A Port B Port C
Port D Port E Port F SOT
7
2k60 4k60 2k80 4k80
14 8 6 No R
A
0-7
G
A
0-7
B
A
0-7
R
B
0-7
G
B
0-7
B
B
0-7
80 22.7 12.0 32.4 17.7
40 19.0 9.7 19.0 9.7
15 8 3 Yes R
0-7
G
0-7
B
0-7
Y
0-7
− −
80 22.7 12.0 32.4 17.7
40 19.0 9.7 19.0 9.7
16 12 3 Yes R
0-7
B
8-11
R
8-11
B
0-7
Y
0-7
G
0-7
Y
8-11
G
8-11
80 22.7 12.0 32.4 17.7
Notes:
1. CLM:Camera Link Mode
2. Bits: Number of bits per pixel
3. Taps: Number of camera link taps per color
4. Luminance: Indicates whether a fourth tap constructed from the RGB using SCC
command is output
5. Time: Time multiplex interval
6. Port : Camera Link port
7. SOT: Output throughput [mega-pixels / second / color]
8. Maximum SSF: Maximum line rate [kHz] possible in this mode (may be reduced by
SAH, ELS and SRM)
CLM 14 Pixels are Interleaved
Port Sequence 1 2 3 4 5 6 7 8 9 10
A Red
A
R1 R3 R5 R7 R9 R11 R13 R15 R17 R19
B Green
A
G1 G3 G5 G7 G9 G11 G13 G15 G17 G19
C Blue
A
B1 B3 B5 B7 B9 B11 B13 B15 B17 B19
D Red
B
R2 R4 R6 R8 R10 R12 R14 R16 R18 R20
E Green
B
G2 G4 G6 G8 G10 G12 G14 G16 G18 G20
F Blue
B
B2 B4 B6 B8 B10 B12 B14 B16 B18 B20
To Next Page
