Piranha Color Camera User’s Manual 30
DALSA 03-032-10211-01 5/9/2007
rgb = adjust all colors (red, green, and blue). Power on
setting.
r = adjust red
g = adjust green
b = adjust blue
Note: The camera always powers up using scl rgb.
Example:
scl b
Color selection limits the taps that can be selected in these commands as follows:
scl
Tap Notes
rgb
0 All 10 camera taps
r
0
1 to 4
All 4 red taps
Single red tap
g
0
1 to 4
All green taps
Single green tap
b
0
1 to 2
All blue taps (2)
Single blue tap
Selecting the Set Number
Purpose: When saving and loading camera settings, you have a choice of
saving up to four different sets and loading from five different
sets (four user and one factory). This command determines the
set number from where these values are loaded and saved. The
set number is saved along with the camera settings when the
wus command is issued.
Syntax:
ssn i
Syntax Elements:
i
0 = Factory set. Settings can only be loaded from this set.
1 - 4 = User sets. You can save, or load settings with these
sets.
Note: The camera powers up with the last set saved using this
command.
Related Commands
wus, lus, wil, lil, wfc, lfc
Example:
ssn 3
Setting a Region of Interest (ROI)
Purpose: Sets the pixel range used to collect the end-of-line statistics and
sets the region of pixels used in the
ccg, gl, gla, ccf, and
ccp commands.
In most applications, the field of view exceeds the required object
size and these extraneous areas should be ignored. It is
recommended that you set the region of interest a few pixels
inside the actual useable image.
Syntax:
roi x1 x2
Syntax Elements:
x1
Column start number. Must be less than the pixel end number
in a range from 1 to sensor resolution.
x2
Column end. Must be greater than the pixel start number in a
range from 1 to sensor resolution.
