Piranha Color Camera User’s Manual 84
DALSA 03-032-10211-01 5/9/2007
Mnemonic Syntax Parameters Description
allowable range.
set fpn coeff sfc x i Set the FPN coefficient. First must
select a single color with SCL.
x =pixel number within the range 1 to
n. Where n = 2048 or 4096.
i= FPN value within the range 0 to
4095 (12-bit LSB).
set fpn range sfr x x i Set a range of pixel FPN coefficients.
First must select a single color with
SCL.
x1=first pixel number of the range.
x2=last pixel number of the range
i=coefficient value in a range from 0
to 4095.
set input LUT sil t a i Set a single value in a LUT. First must
select a single color with SCL.
t = Tap; 1 to 4 depending on color
a = Address within LUT; 0 to 1023
i = Value; -256 to 255
set lower threshold slt i The pixels below the lower threshold
are counted and reported in the end-
of-line sequence.
i = Threshold in a range from 0-
4095.
set mirroring mode smm i Set mirroring mode:
0 = Left to right
1 = Right to left
set output throughput sot m Sets the camera's total throughput per
color. Valid values are: 30, 40, 60, or
80 mega-pixels per second per color.
set prnu coeff spc x i Set a PRNU coefficient. First must
select a single color with SCL.
x=pixel number within the range 1 to
n. Where n = 2048 or 4096.
i= PRNU value within the range 0 to
61438.
set prnu range spr i1 i2 x Set a range of pixel PRNU coefficients.
First must select a single color with
SCL.
i1 = first pixel number of the range
i2 = last pixel number of the range
x = coefficient value in a range from 0
to 61438.
set readout mode srm i Select vertical transfer dark clear mode.
0 = Auto, clears dark below
approximately 60% of maximum line
rate
1 = Always clears dark; reduces the
maximum line rate
2 = Off
set spatial alignment ssa i Set line delay between colors. 0 to 6.
set subtract background ssb t i Subtract this value from the output
signal.
