Piranha Color Camera User’s Manual 9
DALSA 03-032-10211-01 5/9/2007
-10 dB 0 dB +10 dB
Notes
Operating
Specifications
Unit
Min Typ Max Min Typ Max Min Typ Max
pk
FPN ECE
(FFC
disabled)
DN pk to
pk
4 14 12 43 35 137
FPN (FCC
enabled)
pk to pk 9
PRNU ECD
pix to pix
DN rms 350 350
PRNU ECE
pix to pix
DN rms 20 350 350 724
PRNU ECE DN
pk to pk
180 608 608 854
PRNU (FCC
enabled)
ECD
ECE
pk to pk
DN rms
DN rms
61
NEE (RGB) pJ/cm
2
SEE nJ/cm
2
Optical Interface Units Value Notes
Back Focal Distance
M72 Mount
mm 19.56 (M72 x 0.75)
Sensor Alignment
x
y
z
0z
μm
μm
μm
°
± 50
± 50
± 250
Lens Mount M72 x 0.75
Mechanical Interface Units Value Notes
Camera Size mm (l x h x w) 67 x 105 x 76
Mass g 450
Connectors
power connector
data connector
Electrical Interface Units Notes
Input Voltage Volts +12 to +15
Power Dissipation W 12
Operating
Temperature (front
plate)
°C 0 to 50
Data Output Format Bits 8 or 12
