PROCEDURE
Inspecting and replacing timer (Continued)
Step 5:Remove the leads from the Step 6:To remove the timer, remove Step 7:Move leads terminal for
Terminals to be checked. Using an the two timer mounting screws. terminal to the new timer.
ohm meter, check the resistance
through the contact while turning the
timer. If the contacts being checked
do not close at the appropriate times
during the cycle, replace the timer
.
Step 8: Remount new timer Step 9: Reassemble dishwasher, apply
power and test operation.
13
