Ilus Description Qty Per Part
No. Unit No.
1 Door Spring 1 1.398
2 Front Cover Facing Bar 1 2.398
3 Filter Assembly 1 3.398
4 Outer Casing 2 4.398
5 Outer Casing Screw 1 5.398
6 Absorbtion Proofed Connecting Hose 1 6.398
7 Clamp 24 3 7.398
8 Name Plate 1 8.398
9 Inlet Hose 1 9.398
10 Clamp 16 2 10.398
11 Spray Arm Assembly 1 11.398
12 Spray Arm Base Screw 1 12.398
13 Spray Arm Base Gasket 1 13.398
14 Front Cover 1 14.398
15 Bottom Pan 1 15.398
16 Foot 5 16.398
17 Motor Base Rubber Pad 4 17.398
18 Washer 4 18.398
19 Pressure Switch Bracing Bar 1 19.398
20 Pressure Switch (normal) 1 20.398
21 Pressure Switch (safety) 1 21.398
22 Clamp 24 1 22.398
23 Clamp 26 1 23.398
24 Drain pump Drain Hose 1 24.398
25 Clamp 45.1 1 25.398
26 Clip 7 26.398
27 Nut 5 27.398
28 Sump 1 28.398
29 Heating Element 1 29.398
30 Heating Element Gasket 1 30.398
31 Heating Element Mounting Plate 1 31.398
32 Thermostat #1 1 32.398
33 Thermostat #1 Clamp 1 33.398
34 Sump Gasket 1 34.398
35 Thermostat #2 1 35.398
36 Sump Tap 1 36.398
37 Clamp 26 1 37.398
38 Drain pump Inlet Hose 1 38.398
39 Circulation Hose 1 39.398
40 Clamp 41.5 1 40.398
41 Pressure Switch Connecting Hose 1 41.398
