16. Normal Thermostat
The normal thermostat is used to control the water temperature during the wash and final rinse when the sani
option is selected. When the sani option is selected, the timer stops at specific points in the cycle and the heating
element is energized. When the water temperature reaches 154 F or 67.7C the thermostat contacts close and the
timer continues through the cycle. The extra water heating period assures temperatures high enough to produce
good wash results.
PROCEDURE
Inspecting and replacing: Normal Thermostat
Step 1: Be sure all controls are Step 2: This procedure requires the Step 3: The normal thermostat can be
turned OFF. Disconnect power removal of the outer casing. If you accessed from the left side of the dish-
supply at distribution panel or are unfamiliar with this process, please. washer and is on the back of the sump.
unplug power cord from outlet. refer to procedure #7:Removing outer
watch for sharp edges. casing.
Step 4: Using an ohm meter remove the wires Step 5: To replace the normal thermostat
and check for continuity across the thermostat remove the two mounting screws and install
terminals. These contacts should always be the new component.
open at room temperature so if there is any Reassemble dishwasher and check operation.
reading at all the thermostat must be replaced
.
21
Normal thermostat
