PROCEDURE
Inspecting and replacing: Water inlet valve (continued)
Step 7: Disconnect incomming water Step 8: Remove mounting screw that
Water supply hose. Remove clamp secures fill valve to rear panel. Install
and detach smaller hose running into new valve and reconnect leads and
dishwasher tub. water lines. Reassemble dishwasher
and reconnect water and power supply.
NOTE: If water continues to fill, even when power is disconnected, this is caused by damage to, or sediments
in valve housing or bellows. In either case entire valve should be replaced.
NOTE: If open winding in solenoid were proceeded by continuous filling and draining. Make sure timer is
Advancing through the fill cycle. Continuous duty will burn out water valve solenoid.
17
