d&b audiotechnik SL Series Rigging Manual

SUB columns
Rear link adapter
The Rear link adapter is located in its park position at the front of
the Frame's center truss.
1. Unlock and remove the ring cotter of the fixing bolt holding the
Rear link adapter in its park position.
2. Pull out the fixing bolt and remove the Rear link adapter.
3. For the Rear link of the frame, proceed in the same manner.
4. Attach the Rear link to the adapter.
5. Insert the fixing bolt.
6. Secure the fixing bolt using the ring cotter and ensure the ring
cotter is properly locked.
d&b SL-Series Rigging manual 1.10 en 59
