D&H PD05A - Locomotive Decoder Functions and Operation

20
Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
20
Locomotive/Locomotive function decoder from firmware version 3.12
5.1 Functions
• Operation can be controlled either by conventional DC command stations or by digital central units supporting the
formats SelecTRIX 1 and 2, NMRA standard (DCC) or MM1/MM2 standard
• Automatic switch over from conventional DC to digital operation
• In case of digital operation the last programmed system will be activated. Automatic switching into a certain
operating mode is not possible because of the multiprotocol operation. For switching a parameter (e.g. locomotive
address) is to be readout and must be written again in the required operating mode. Thus the switching to the
required track protocol is completed.
• SelecTRIX 1 ..... 31 speed steps, 100 addresses
• SelecTRIX 2 ..... 127 speed steps, 10.000 addresses, 16 additional functions
• DCC
................. short addresses (1-127), long addresses (0001-9999), with 14, 28, 126 speed steps
•
State of art load regulation, in this way an especially smooth control mode
• Different control variants for an optimal adaption to the motor
• 127 internal speed steps
• Adjustable motor frequency (low frequency, 16 kHz, 32 kHz)
• Block section operation by simple diodes in digital operation
• Light and function outputs are (partly) dimmable and can be activated analogously
• Shunting gear
• Motor, light and track connections electronically changeable
• All function outputs are freely programmable
• Thermal protection
• Reset function for DCC and SX2
• Updateability of the decoder
