Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
52
Locomotive/Locomotive function decoder from firmware version 3.12
Supplement 1: Notes to Function Mapping
If you want to activate a function enter the value of the corresponding output according to the following table. In case you
want to activate several different functions simultanously you must add up the related values.
Output values:
RG/AUX6 ABL/AUX5 AUX4 AUX3 AUX2 AUX1 LR LV
Value
128
64 32 16 8 4 2 1
RG = shunting gear ABL = low beam light
Example: F4 should activate the shunting gear and switch on the outputs LV and LR:
LV=1, LR=2, RG=128: so you must enter the value 131 in CV38 | par066.
Notice:
If CV137 | par088 Bit4 is not active (normal mapping):
V
alue 128 operates the shunting gear, value 64 operates the low beam.
AUX6 and AUX5 are not usable in this case and CV132-134 | par147-149 have no meaning.
If CV137 | par088 bit4 is active (extended mapping):
V
alue 128 operates AUX6, value 64 operates AUX5.
The shunting mode is controlled by CV132 | par147, the low beam is controlled by CV133 | par148.
With CV133 | par149 the delays (CV03, 04 | par011, 012) can be switched off.
Timer function (CV117-120, 129, 130, par076-079, 145, 146)
Value = 0 The timer is switched off (continuous function)
V
alue = 1…250
The timer is activated, the coressponding output will be disconnected after the time of:
entered value x 0.1 [sec].
