D&H PD05A - List of Supported CV

37
Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
37
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
01
Address (not relevant to PD*)
Addresses higher than 127 are only usable in MM-operation
1-255
3
02
Starting voltage
0-15 0
03
Acceleration time
The value corresponds to the time in seconds from start to maximum speed
0-255 3
04
Deceleration time
The value corresponds to the time in seconds from the maximum speed to stop
0-255 3
05 Maximum speed
(see supplement 2) 0-127 92
07 V
ersion number
(read only)
08 Manufacturer identification
(read only)
97 = Doehler & Haass (Decoder reset with “8“)
09 Motor frequency
(not relevant to FH*)
Bit Function Value
0........0 = 32 kHz, 1 = 16 kHz .......................................................................... 1
1........0 = 16/32 kHz, 1 = low frequency ......................................................... 2
2........proportional part limitation .................................................................... 4
3........Switch off short circuit protection ......................................................... 8
0-15 1
8.2.1 List of supported CV
The abbreviation FH* refers to the decoder types FH05B, FH18A and FH22A.
The abbreviation PD* refers to decoder types PD05A, PD06A, PD12A, PD18A and PD21A.
