Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
38
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
12
MM settings (not relevant to PD*)
Bit 0-2:
0 = MM-operation deaktivated
1 = MM-operation without additional address
2 = MM-operation with one additional address
3 = MM-operation with two additional addresses
4 = MM-operation with three additional addresses
5 = MM-operation with four additional addresses
6 = MM-operation with five additional addresses
7 = MM-operation with six additional addresses
Bit 3 = decoder internal use: driving direction at MM1/AC analog
0-15 1
13 Analog mode F1-F8 (not relevant to PD05A)
Bit Function Value Bit Function Value
0...................F1 .................. 1 4 .................. F5 .................. 16
1...................F2 .................. 2 5 .................. F6 .................. 32
2...................F3 .................. 4 6 .................. F7 .................. 64
3...................F4 .................. 8 7 .................. F8 ................ 128
This setting is also valid for MM1 operation.
0-255 1
14 Analog mode F0, F9-F12 (not relevant to PD05A)
Bit Function Value Bit Function Value
0...................F0 (f) ............... 1 4 .................. F11 ................ 16
1...................F0 (r) ............... 2 5 .................. F12 ................ 32
2...................F9 ................... 4
3...................F10 ................. 8
This setting is also valid for MM1 operation.
0-63 3
