Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
32
Locomotive/Locomotive function decoder from firmware version 3.12
The locomotive function decoder correspond functionally completely with the decoders described in point 5. Only features
in direct connection with the engine control are missing. This fact is marked in the setting options of the corresponding
system format. See:
- Point 7.2
- Point 8.2: CV09, CV49, CV50, CV51/Bit 0, CV56 – CV59, CV112
- Point 10.2: par017, par032, par052 – par054, par056 – par059
6.2 Installation of the locomotive function decoder
See notice in point 5.2.
6.3 Connection of the locomotive function decoder
There are following variants to connect the locomotive function decoder FH05B:
1 In case your locomotive is equipped with an interface according to NEM 651, use decoder FH05B-1. It has already the
appropriate connections for this plug. Short the ribbon cable up to approximately 5 mm and remove the rest of the
insulation. The decoder can be inserted into the interface without any problem now.
ATTENTION:
The additional functions AUX1 and AUX2 are issued to those interface lines at which in locomotive decoders the motor
is connected. Therefore FH05B-1 should not be installed in a 6 pin interface of a locomotive with engine.
2 In case your locomotive has no interface socket, use decoder FH05B-3 and wire it individually.
3 Decoder FH05B-0 should be used only by experienced model railroaders, as the connection wires must be soldered
directly onto the decoder.
There are following variants for the connection of the locomotive function decoder FH18A:
4 In case your locomotive is equipped with an interface according to NEM 651, you need for FH18A the connecting
adapter N18-K-1. It has already the appropriate connections for this plug. Short the ribbon cable up to approximately 5 mm
and remove the rest of the insulation. The decoder can be inserted into the interface without any problem now.
