Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
39
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
17
18
Extended address
CV17 contains the most significant byte; CV18 contains the least significant byte.
Only, if activated by CV29/Bit 5=1.
0-255
0-255
195
232
19
Consist address
Several compound locomotives run under this address (1-127)
0, 128 = deactivated
Value + 128 = inverse direction
0-255
0
21
Consist mode F1-F8
Bit
Function
Value
Bit Function
Value
0...................F1 ................... 1 4 .................. F5 ..................16
1...................F2 ................... 2 5 .................. F6 ..................32
2...................F3 ................... 4 6 .................. F7 ..................64
3...................F4 ................... 8 7 .................. F8 ................128
0-255 0
22 Consist mode F0, F9-F12
Bit
Function
Value
Bit Function
Value
0...................F0 (f) ............... 1 4 .................. F11 ................ 16
1...................F0 (r) ............... 2 5 .................. F12 ................ 32
2...................F9 ................... 4
3...................F10 ................. 8
0-63 0
27 Brake settings
Bit Function Value Bit Function Value
0........Asymmetry normal ............. 1 4......Negative voltage ...............16
1........Asymmetry inverse ............ 2 5......Positive voltage .................32
2........Currently without function .. 4 6......Brake diode normal ...........64
3........Currently without function .. 8 7......Brake diode inverse .........128
0-243 64
