Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
40
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
28
Check-back settings
Bit Function Value
0........Channel 1 (Locomotive address) allowed ...... 1
1........Channel 2 (POM readout etc.) allowed ......... 2
2........Dynamic channel utilization ........................... 4
0-7
3
29
Configuration register
Bit Function Value
0........Inverse direction ............................................ 1
1........ 14 speed steps .............................................. 0
28/126 speed steps ....................................... 2
2........Analog operation allowed .............................. 4
(not relevant to PD05A)
3........Check back allowed ....................................... 8
5........Locomotive address by CV17/18 ................. 32
0-255
14
33
Function mapping F0(f) (see supplement 1)
0-255 1
34
Function mapping F0(r) (see supplement 1)
0-255 2
35 Function mapping F1(f+r) (see supplement 1)
If CV35 is written, CV47 will be set to the same value
0-255 4
36 Function mapping F2(f+r) (see supplement 1)
If CV36 is written, CV64 will be set to the same value
0-255 8
37 Function mapping F3
(see supplement 1) 0-255 16
38 Function mapping F4 (see supplement 1) 0-255 128
39 Function mapping F5 (see supplement 1) 0-255 32
40 Function mapping F6
(see supplement 1) 0-255 0
