Locomotive/Locomotive function decoder from firmware version 3.12
Using the coupling function of our decoder it must be ensured that the function output will be switched off in any
case according to a maximum activation time specified by you. Otherwise the destruction of the electric coupling
is possible.
The time, while coupling is activated, is defined by the switching off function:
CV117 Timer for switching off AUX1
CV118
T
imer for switching off AUX2
CV119 Timer for switching off AUX3
CV120 Timer for switching off AUX4
CV129
T
imer for switching off AUX5
CV130 Timer for switching off AUX6
Please proceed as follows:
For function output AUX1 please use CV 117 (par076)
For function output AUX2 please use CV 118 (par077)
For function output AUX3 please use CV 119 (par078)
For function output AUX4 please use CV 120 (par079)
For function output AUX5 please use CV 129 (par145)
For function output AUX6 please use CV 130 (par146)
The adjusted value is internal multiplied by 100 milliseconds. If you want for example to achieve a maximum activation time
of one second, please program the value 10.
Value 0 means no coupling function.
That a coupling waltz should be executed the decoder recognizes by the fact that a value unevenly 0 is entered at different
times.
