Lyra Digital Mixer from D&R Phone +31 294 418014, email: info@d-r.nl Page 35
11.2 System information
The System information screen displays the general status of the Lyra.
Figure 24: System Information
Name/Description
Displays the networking name for the Lyra.
Location
Displays the name of the location where the Lyra is active.
Contact
Displays the name of the person here who has administrator
privileges on the Lyra.
Version String
Displays the version of the internal software and the release date
FPGA Version String
Displays the version of the FPGA software
MAC Address
Displays the MAC address of the Lyra (Unique Lyra/Ethernet identifier)
System Up Time
Displays the online time from the last time the Lyra was activated
Sample rate
Displays the sample rate currently used by the Lyra
Control Surface 1
Displays if a control surface is connected on channel 1. Module 1..4
User
Displays which user operates control surface 1. Logon occurs by
chipcard.
Control Surface 2
Displays if a control surface is connected on channel 2 Module 5..8
User
Displays which user operates control surface 2. Logon occurs by
chipcard.
Cobranet
Displays if Cobranet is installed
Internal Temperature
Displays the internal temperature of the 19" rack
Internal Voltage
Displays the voltage of the 5V rail inside the 19" rack
