InstallationGuideECLComfort210/310,applicationA214/A314
A314.3

Heatingwithroomtemperaturecontrol



























 
TypicalA314.3application:
ECL 310
S 3
P 2
S 5
M1
S 6
X3
S 7
F1 / V1
S 8
S 8
S 8
S 1
Da nfos s 87 H213 1.1 2
A1
S10
+ ECA 32
S 4
S 2



Listofcomponents:
ECL310
ElectroniccontrollerECLComfort310
ECA32
Built-inextensionmodule
S1
Outdoortemperaturesensor
S2
(Optional)Compensationtemperaturesensor
S3Ducttemperaturesensor
S4
Roomtemperaturesensor*
S5
(Optional)Returntemperaturesensor
S6
(Optional)Frosttemperaturesensor
S7
(Optional)Frostthermostat
S8
(Optional)Firethermostat
S10
Windspeedsignal(0-10volt)
F1
Fan(ON/OFF)
P2
Damper(ON/OFF)
X3
Circulationpump,heating(ON/OFF)
M1
Motorizedcontrolvalve,heating(3-pointcontrolled)
M2
Motorizeddamper(0-10voltcontrolled)
V1
Fanspeed(0-10voltcontrolled)
A1
Alarm
*Alternative:ECA30



