Danfoss 102E7 User Manual

11
DANFOSS RANDALL 102E7 Water
ON
Heating
ON
COM
MAINS SUPPLY
(via 3 amp fuse)
An additional terminal block is
required where these disconnected
leads (or pairs of leads) should be
terminated
1 2 3 5 (N) 6 (L) A B C
SMITHS IND. CENTROLLER 100
32 - NL1 4
SMITHS IND. CENTROLLER 60
54 - 123
SMITHS IND. CENTROLLER 10
3 2 - N L 1,4
SMITHS IND. CENTROLLER 70
54 - 123 6
SWITCHMASTER 320, 350 3 1 - N 4,L 2 SWITCHMASTER 600 3 1 - N L 2 4 VENNER VENOTROL V S,F - N,A,M L,L1 T,P 0 VENNER VENOTROL 80 (Air ‘Stat)
2 A/S - N,1,3 L A/S,5
VENNER VENOTROL 80 (Air ‘Stat Linked)
2 5 - N,1,3 L
Replacement

Danfoss 102E7 Specifications

General

Brand	Danfoss
Model	102E7
Category	Thermostat
Language	English
