Danfoss 90 Series Service Manual

Fastener size and torque chart
Item Fastener Frame size Wrench size Torque
B83 Speed sensor lock nut 030-250 1-1/16 in hex 13.5 N•m [10 lbf•ft]
E60 Side cover screw
Blind holes
030-042 10 mm hex 13.5 N•m [10 lbf•ft]
055-100 13 mm hex 32 N•m [24 lbf•ft]
130-250 17 mm hex 64 N•m [37 lbf•ft]
E60 Side cover screw
Thru holes
030-042 10 mm hex 10.4 N•m [7.7 lbf•ft]
055-100 13 mm hex 32 N•m [24 lbf•ft]
130-250 17 mm hex 32 N•m [47 lbf•ft]
F111/
F211
Servo cylinder screw 030-055 8 mm hex 13.5 N•m [10 lbf•ft]
075-250 10 mm hex 32.5 N•m [24 lbf•ft]
G90/G9
7
End cap screw 030-042 5 mm internal hex 13.5 N•m [10 lbf•ft]
055-100 6 mm internal hex 32.4 N•m [24 lbf•ft]
130 10 mm hex 38 N•m [28 lbf•ft]
180-250 10 mm hex 110 N•m [81 lbf•ft]
H80 Charge pump retaining screw 030-100 10 mm hex 16 N•m [11.85 lbf•ft]
130-250 13 mm hex 32 N•m [24 lbf•ft]
J80 End cap screw 030 8 mm internal hex 58 N•m [43 lbf•ft]
early 042 8 mm internal hex 75 N•m [55 lbf•ft]
late 042 10 mm internal hex 75 N•m [55 lbf•ft]
055 19 mm hex 122 N•m [90 lbf•ft]
075-100 24 mm hex 298 N•m [220 lbf•ft]
100-130 14 mm internal hex 298 N•m [220 lbf•ft]
180-250 17 mm internal hex 580 N•m [429 lbf•ft]
K10 Charge pressure valve plug 030-250 1/2 in hex NA
K90 Charge pressure lock nut 030-100 1-1/16 in hex 52 N•m [38 lbf•ft]
130-250 1-5/8 in hex 52 N•m [38 lbf•ft]
L70 Shaft retaining screw 030-042 10 mm hex 12 N•m [9 lbf•ft]
055-100 5 mm internal hex 16 N•m [12 lbf•ft]
130-250 6 mm internal hex 32 N•m [24 lbf•ft]
M72 MDC handle nut 030-250 8 mm 13.5 N•m [10 lbf•ft]
M78 De-stroke valve manifold screw 030-250 5 mm internal hex 13.5 N•m [10 lbf•ft]
M85 Eccentric plug lock nut 030-250 1-1/8 in hex 27 N•m [20 lbf•ft]
M88 Neutral start switch lock nut 030-250 1-1/8 in hex 27 N•m [20 lbf•ft]
M90 Control mounting screw 030-250 5 mm internal hex 16 N•m [12 lbf•ft]
M92 Solenoid valve mounting screw 030-250 4 mm internal hex 5.4 N•m [4 lbf•ft]
M98 PCP mounting screw 030-250 4 mm internal hex 5.4 N•m [4 lbf•ft]
N10 Filter reducer assembly 030-042 1-1/4 in hex 70 N•m [52 lbf•ft]
055-130 1-1/2 in hex 122 N•m [90 lbf•ft]
180-250 1-1/2 in hex 156 N•m [115 lbf•ft]
N37 Filter plug assembly 030-250 1/4 in internal hex 27 N•m [20 lbf•ft]
Service Manual Series 90 Pumps
Torque chart
68 520L0818 • Rev 0101 • August 2015
