The system circuit
The basic closed circuit
Hydraulic lines connect the main ports of the pump to the main ports of the motor. Fluid flows in either
direction from the pump to the motor then back to the pump in this closed circuit. Either of the hydraulic
lines can be under high pressure. In pumping mode the position of the pump swashplate determines
which line is high pressure as well as the direction of fluid flow.
Service Manual
Series 90 Pumps
Introduction
8 520L0818 • Rev 0101 • August 2015
