3.13.4 16-3* Drive Status
Parameters for reporting the status of the frequency converter.
16-30 DC Link Voltage
Range: Function:
0 V* [0 - 10000 V] View a measured value. The value is filtered with an 30 ms time constant.
16-32 Brake Energy /s
Range: Function:
0.000 kW* [0.000 - 675000.000 kW] View the brake power transmitted to an external brake resistor, stated as an instantaneous value.
16-33 Brake Energy /2 min
Range: Function:
0.000 kW* [0.000 - 500.000 kW] View the brake power transmitted to an external brake resistor. The mean power is calculated on
an average basis for the most recent 120 seconds.
16-34 Heatsink Temp.
Range: Function:
0 C* [0 - 255 C] View the frequency converter heatsink temperature. The cut-out limit is 90 ± 5 °C, and the motor
cuts back in at 60 ± 5 °C.
16-35 Inverter Thermal
Range: Function:
0 %* [0 - 100 %] View the percentage load on the inverter.
16-36 Inv. Nom. Current
Range: Function:
10.00 A* [0.01 - 10000.00 A] View the inverter nominal current, which should match the nameplate data on the connected motor.
The data are used for calculation of torque, motor protection, etc.
16-37 Inv. Max. Current
Range: Function:
16.00 A* [0.01 - 10000.00 A] The current that AKD102 can deliver during 1 min. / 10 min. This value changes depending on
whether it is a high overload or normal overload application. The data are used for calculation of
torque, motor protection, etc.
16-38 SL Controller State
Range: Function:
0 N/A* [0 - 100 N/A] View the state of the event under execution by the SL controller.
16-39 Control Card Temp.
Range: Function:
0 C* [0 - 100 C] View the temperature on the control card, stated in °C.
16-40 Logging Buffer Full
Option: Function:
View whether the logging buffer is full (see par. 15-1*). The logging buffer will never be full when
par.15-13
Logging Mode
is set to
Log always
[0].
[0] * No
[1] Yes
3 Parameter Description ADAP-KOOL
®
Drive Programming Guide
136
MG.11.N1.02 - VLT
®
is a registered Danfoss trademark
3
