3 Parameter Description
3.1 Parameter Selection
3.1.1 Main Menu Structure
Parameters for the frequency converter are grouped into various parameter groups for easy selection of the correct parameters for optimized operation
of the frequency converter.
The vast majority of ADAP-KOOL Drive AKD 102 applications can be programmed using the Quick Menu button and selecting the parameters under Quick
Setup and Function Setups.
Descriptions and default settings of parameters may be found under the section Parameter Lists at the back of this manual.
0-xx Operation/Display 16-xx Data Readouts
1-xx Load/Motor 18-xx Info & Readouts
2-xx Brakes 20-xx Internal Control
3-xx Reference/Ramps 21-xx Extended PID
4-xx Limits/ Warnings 22-xx Application Functions
5-xx Digital In/Out 23-xx Time Based Functions
6-xx Analog In/Out 24-xx Application Functions 2
8-xx Comm. and Options 25-xx Pack Controller
13-xx Smart Logic Controller 26-xx Analog I/O Option MCB 109*
14-xx Special Functions 28-xx Compressor Functions
* Only when installed
3.2 Main Menu - Operation and Display - Group 0
3.2.1 0-** Operation / Display
Parameters related to the fundamental functions of the frequency converter, function of the LCP buttons and configuration of the LCP display.
3.2.2 0-0* Basic Settings
Parameter group for basic frequency converter settings.
0-01 Language
Option: Function:
Defines the language to be used in the display. The frequency converter can be delivered with 4
different language packages. English and German are included in all packages. English cannot be
erased or manipulated.
[0] * English Part of Language packages 1 - 4
[1] Deutsch Part of Language packages 1 - 4
[2] Francais Part of Language package 1
[3] Dansk Part of Language package 1
[4] Spanish Part of Language package 1
[5] Italiano Part of Language package 1
[7] Nederlands Part of Language package 1
ADAP-KOOL
®
Drive Programming Guide 3 Parameter Description
MG.11.N1.02 - VLT
®
is a registered Danfoss trademark
31
3
