6-62 Terminal X30/8 Max. Scale
Range: Function:
100.00 %* [0.00 - 200.00 %] Scales the maximum output of the selected analog signal on terminal X30/8. Scale the value to the
desired maximum value of the current signal output. Scale the output to give a lower current than
20 mA at full scale or 20 mA at an output below 100% of the maximum signal value. If 20 mA is
the desired output current at a value between 0 - 100% of the ful-scale output, program the per-
centage value in the parameter, i.e. 50% = 20 mA. If a current between 4 and 20 mA is desired at
maximum output (100%), calculate the percentage value as follows:
20
mA
/
desired
maximum
current
× 100%
i
.
e
. 10
mA
:
20
mA
10
mA
× 100% =200%
6-63 Terminal X30/8 Output Bus Control
Range: Function:
0.00 %* [0.00 - 100.00 %] Contains the value to apply to the output terminal, when it is configured as [Bus Controlled].
6-64 Terminal X30/8 Output Timeout Preset
Range: Function:
0.00 %* [0.00 - 100.00 %] Contains the value to apply to the output terminal, when it is configured as [Bus Controlled Timeout]
and time-out is detected.
3 Parameter Description ADAP-KOOL
®
Drive Programming Guide
94
MG.11.N1.02 - VLT
®
is a registered Danfoss trademark
3
