AKD 2800
NB!:
Upload/download can only be performed
in stop mode. Download can o
nly be
performed to a frequency converter with
the same software version number, see parameter
626 Database identification no.
008 Display scaling of output frequency
(FREQUENCY SCALE)
Value:
0.01 - 100.00
✭ 1.00
Function:
In this parameter, the factor is selected by which the
output frequency is to be multiplied. The value is shown
in the display, provided parameters 009-012 Display
readout have been set to Output frequency x scaling [5].
Description of choice:
Set the required scaling factor.
009 Large display readout
(DISPLAY LINE 2)
Value:
No readout (NONE)
[0]
Resulting reference [%]
(REFERENCE [%] )
[1]
Resulting reference [unit]
(REFERENCE [UNIT])
[2]
Feedback [unit] (FEEDBACK [UNIT])
[3]
✭Frequency [Hz] (FREQUENCY [HZ])
[4]
Output frequency x scaling
(FREQUENCY X SCALE)
[5]
Motor current [A] (MOTOR CURRENT [A])
[6]
Torque [%] (TORQUE [%])
[7]
Power [kW] (POWER [KW])
[8]
Power [HP] (POWER [HP][US])
[9]
Motor voltage [V]
(MOTOR VOLTAGE [V] )
[11]
DC link voltage [V]
(DC LINK VOLTAGE [V])
[12]
Thermal load motor [%]
(MOTOR THERMAL [%])
[13]
Thermal load [%]
(FC. THERMAL[%])
[14]
Running hours [Hours]
(RUNNING HOURS] )
[15]
Digital input [Bin]
(DIGITAL INPUT[BIN] )
[16]
Analog input 53 [V]
(ANALOG INPUT 53 [V])
[17]
Analog input 60 [mA]
(ANALOG INPUT 60 [MA])
[19]
Pulse reference [Hz]
(PULSE REF. [HZ] )
[20]
External reference [%]
(EXTERNAL REF. [%])
[21]
Status word [Hex] (STATUS WORD [HEX])
[22]
Heatsink temperature [°C]
(HEATSINK TEMP [°C])
[25]
Alarm word [Hex] (ALARM WORD [HEX])
[26]
Control word [Hex] (CONTROL WORD [HEX])
[27]
Warning word [Hex]
(WARNING WORD [HEX] )
[28]
Extended status word [Hex]
(EXT. STATUS [HEX])
[29]
Communication option card warning
( COMM OPT WARN [HEX])
[30]
Pulse count
(PULSE COUNTER)
[31]
Function:
In this parameter you can select the data value that
you wish to display in the LCP control unit display
line 2 when the frequency converter is switched
on. The display will also be included in the scrollbar
in display mode. In parameters 010-012 Display
readout you can select a further three data values,
which are displayed in display line 1.
Description of choice:
No readout can only be selected in parameters
010-012 Small display readout.
Resulting reference [%] gives, as a percentage,
the resulting reference in the range from Minimum
reference, Ref
MIN
to Maximum reference, Ref
MAX
.
Reference [unit] gives the resulting reference with unit
Hz in Open loop.InClosed loop the reference unit
is selected in parameter 416 Process units.
Feedback [unit] gives the resulting signal value
using the unit/scaling selected in parameter 414
Minimum feedback, FB
LOW
, 415 Maximum feedback,
FB
HIGH
and 416 Process units.
Frequency [Hz] gives the output frequency of
the frequency converter.
Output frequency x scaling [-] equals the present output
frequency f
M
multiplied by the factor set in parameter
008 Display scaling of output frequency .
Motor current [A] gives the phase current of the
motor measured as an effective value.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.28.H2.02 -
14
