Danfoss AMV213

Adjustments AME210, AME213
39
7.4 Assignment of the effective direction to the input/output signal
Valves: VIM2, VIS2, AIQM
Valve: VIU2
S2
0 Stroke 100 %
0(2-4)
20 mA
10 V
1 2 3 4 5 6 7 8
ON
Input,
signal
output
S2
0 Stroke 100 %
0(2-4)
20 mA
10 V
1 2 3 4 5 6 7 8
ON
Input,
signal
output
S2
0 Stroke 100 %
0(2-4)
20 mA
10 V
1 2 3 4 5 6 7 8
ON
Input,
signal
output
S2
0 Stroke 100 %
0(2-4)
20 mA
10 V
1 2 3 4 5 6 7 8
ON
Input,
signal
output
Inverse operation
Normal operation
