FC 300 Design Guide
How to Program
Below I low [8]
Above I high [9]
Below speed low [11]
Above speed high [12]
Thermal warning [16]
Mains voltage out of range [17]
Reversing [18]
Warning [19]
Alarm (trip) [20]
Alarm (trip lo ck) [21]
Comparator 0 [22]
Comparator 1 [23]
Comparator 2 [24]
Comparator 3 [25]
Logic rule 0 [26]
Logic rule 1 [27]
Logic rule 2 [28]
Logic rule 3 [29]
Time-out 0 [30]
Time-out 1 [31]
Time-out 2 [32]
Digital input DI18 [33]
Digital input DI19 [34]
Digital input DI27 [35]
Digital input DI29 [36]
Digital input DI32 [37]
Digital input DI33 [38]
Function:
Same as in par. 13-40.
" 13-5* Smart Logic C ontroller
13-51 SL Controller Event
Array [6]
Option:
*
False [0]
True [1]
Running [2]
In range [3]
On reference [4]
To rque lim it [5]
Current limit [6]
Out of current range [7]
Below I low [8]
Above I high [9]
Below speed low [11]
Above speed high [12]
Thermal warning [16]
Mains voltage out of range [17]
Reversing [18]
Warning [19]
Alarm (trip) [20]
Alarm (trip lock) [21 ]
Comparator 0 [22]
Comparator 1 [23]
Comparator 2 [24]
Comparator 3 [25]
Logic rule 0 [26 ]
Logic rule 1 [27 ]
Logic rule 2 [28 ]
Logic rule 3 [29 ]
Time-out 0 [30]
Time-out 1 [31]
Time-out 2 [32]
Digital input DI18 [33]
Digital input DI19 [34]
Digital input DI27 [35]
Digital input DI29 [36]
Digital input DI32 [37]
Digital input DI33 [38]
Function:
Selects the Boolean input (TRUE or FALSE)
to define this event.
• *False [0] - enters the fixed value
FALSE in the event.
• True [1] - enters the fixed value TRUE
in the event.
• Running [2] - see par. 5-31 for further
description.
• In range [3] - see par. 5-31 for further
description.
• On refere nce [4] - see par. 5-31 for
further description.
• To rque limit [5] - see pa r. 5-31 for
further description.
• Current limit [6 ] - see par. 5-31 for
further description.
• Out of current range [7] - see par. 5-31
for further description.
• Above I low [8] - s ee par. 5-31 for
further description.
• Below I high [9] - see par. 5-31 f or
further description.
• Above frequency low [11] - see par. 5-31
for further description.
• Below f requency high [12] - see pa r. 5 -31
for further description.
*
default setting ()display text []value for use in communication via serial communication port
202
MG.33.B
3.22 - VLT is a registered Danfoss trademark
