FC 300 Design Guide
How to Program
• Select set-up 1 [2] - changes the active
set-up (par. 0-10 ) to "1".
• Select set-up 2 [3] - changes the active
set-up (par. 0-10 ) to "2".
• Select set-up 3 [4] - changes the active
set-up (par. 0-10 ) to "3".
• Select set-up 4 [5] - changes the active set-up
(par. 0-10) to "4". If you change the set-up, it
will m erg e with other set-up com mands coming
from either the digital inputs or via a fieldbu s.
• Select preset reference 0 [10] - selects
preset reference 0.
• Select preset reference 1 [11] - selects
preset reference 1.
• Select preset reference 2 [12] - selects
preset reference 2.
• Select preset reference 3 [13] - selects
preset reference 3.
• Select preset reference 4 [14] - selects
preset reference 4.
• Select preset reference 5 [15] - selects
preset reference 5.
• Select preset reference 6 [16] - selects
preset reference 6.
• Select preset refere nce 7 [17] - se lects preset
reference 7. If you chang e the active preset
reference, it will merge with other preset
reference commands coming from either the
digital inputs or via a fieldbus.
• Select ramp 1 [18 ] - selects ramp 1.
• Select ramp 2 [19 ] - selects ramp 2.
• Select ramp 3 [20 ] - selects ramp 3.
• Select ramp 4 [21 ] - selects ramp 4.
• Run [22] - issues a start comm and to the drive.
• Run reverse [23] - issues a start reverse
command to the drive.
• Stop [24] - issues a stop command to the drive.
• Qstop [25] - issues a quick stop command
to the drive.
• Dcstop [2 6] - issues a DC stop command
to the drive.
• Coast [27] - the drive coasts immediately.
All stop c ommands including the coast
command stop the SLC.
• Freeze output [28]-freezestheoutput
frequency of the drive.
• Start timer 0 [29]-startstimer0,seepar.
13-20 for further description.
• Start timer 1 [30]-startstimer1,seepar.
13-20 for further description.
• Start tim er 2 [31] - starts timer 2, see par.
13-20 for further d esc ription.
• Set digital output A low [32] - any output with
"digital output 1" selected is low (open).
• Set digital output B low [33] - any outp ut with
"digital output 2" selected is low (off).
• Set digital output C low [34] - any output with
"digital output 3" selected is low (off).
• Set digital output D low [35] - any output with
"digital output 4" selected is low (off).
• Set digital output E low [36] - any output with
"digital output 5" selected is low (off).
• Set digital output F low [37] - any output with
"digital output 6" selected is low (off).
• Set digitaloutputAhigh[38] - any output with
"digital output 1" selected is high (cl o sed).
• Set digital output B high [39 ] - any output with
"digital output 2" selected is high (cl o sed).
• Set digital output C high [40] - any output with
"digital output 3" selected is high (cl o sed).
• Set digital output D high [41] - any output with
"digital output 4" selected is high (cl o sed).
• Set digital output E high [42] - any outp ut with
"digital output 5" selected is high (cl o sed).
• Set digital output F high [43] - any outp ut with
"digital output 6" selected is high (cl o sed).
*
