FC 300 Design Guide
How to Program
" 6-** Analog In/Out
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
6-0* Analog IO mode
6-00 Live zero Timeout Time 10 s All set-ups TRUE 0 Uint8
6-01 Live zero Timeout Function [0] Off All set-ups TRUE - Uint8
6-1* Analog input 1
6-10 Terminal 53 low voltage 0.07 V All set-ups TRUE -2 Int16
6-11 Terminal 53 high voltage 10.00 V All set-ups TRUE -2 Int16
6-12 Terminal 53 low current 0.14 mA All set-ups TRUE -5 Int16
6-13 Terminal 53 high current 20.00 mA All set-ups TRUE -5 Int16
6-14 Terminal 53 low ref./feedb. value 0.000 Unit All set-ups TRUE -3 Int32
6-15 Terminal 53 high ref./fee db. value 1500.000 Unit All set-ups TRUE -3 Int32
6-16 Terminal 53 filter time constant 0.001 s All set-ups FALSE -3 Uint16
6-2* Analog input 2
6-20 Terminal 54 low voltage 0.07 V All set-ups TRUE -2 Int16
6-21 Terminal 54 high voltage 10.00 V All set-ups TRUE -2 Int16
6-22 Terminal 54 low current 0.14 mA All set-ups TRUE -5 Int16
6-23 Terminal 54 high current 20.00 mA All set-ups TRUE -5 Int16
6-24 Terminal 54 low ref./feedb. value 0.000 Unit All set-ups TRUE -3 Int32
6-25 Terminal 54 high ref./fee db. value 1500.000 Unit All set-ups TRUE -3 Int32
6-26 Terminal 54 filter time constant 0.001 s All set-ups FALSE -3 Uint16
6-5* Analog output 1
6-50 Terminal 42 output [0] No operation All set-ups TRUE - Uint8
6-51 Terminal 42 output min scale 0.00 % All set-ups TRUE -2 Int16
6-52 Terminal 42 output max scale 100.0 0 % All set-ups TRUE -2 Int16
" 7-** Controller s
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
7-0* Speed PID ctrl.
7-02 Speed PID proportional gain 0.015 All set-ups TRUE -3 Uint16
7-03 Speed PID Integral Time Drive dependent All set-ups TRUE -4 Uint32
7-04 Speed PID differentiation time Drive dependent All set-ups TRUE -4 Uint16
7-05 Speed PID diff. gain Limit 5.0 All set-ups TRUE -1 Uint16
7-06 Speed PID lowpass filter time 10.0 ms All set-ups TRUE -4 Uint16
*
default setting ()display text []value for use in communication via serial c ommunication port
227
MG.33.B
3.22 - VLT is a registered Danfoss trademark
