FC 300 Design Guide
How to Program
" 8-** Comm. and options
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
8-0* General settings
8-00 Enabled o ptions [1] All All set-ups FA LSE - Uint8
8-01 Control site [0] Digital and ctrl.word All set-ups TRUE - Uint8
8-02 Controlword source [0] FC RS485 All set-ups TRUE - Uint8
8-03 Controlword Timeout Time 1.0 s 1 set-up TRUE -1 Uint32
8-04 Controlword Timeout Function [0] Off 1 set-up FALSE - Uint8
8-05 End-of-timeout function [1] Resume set-up 1 set-up TRUE - Uint8
8-06 Reset Controlword Timeout [0] Do not reset All set-ups TRUE - Uint8
8-07 Diagnosis trigger [0] Disable 2 set-ups FALSE - Uint8
8-1* Ctrl. word settings
8-10 Control word profile [0] FC profile All set-ups TRUE - Uint8
8-3* FC Port set tings
8-30 Protocol [0] FC 1 set-up FALSE - Uint8
8-31 Address 1 1 set-up FALSE 0 Uint8
8-32 FC port baudrate [2] 9600 Ba ud 1 set-up FALSE - Uint8
8-35 Minimum response delay 10 ms All set-ups FALSE -3 Uint16
8-36 Max response delay 5000 ms 1 set-up FALSE -3 Uint16
8-37 Max inter-char delay 25 ms 1 set-up FALSE -3 Uint16
8-5* Digital/Bus
8-50 Coasting select [3] Logic OR All set-ups TRUE - Uint8
8-51 Quick stop selec t [3] Logic OR All set-ups TRUE - Uint8
8-52 DC Brake select [3] Logic OR All set-ups TRUE - Uint8
8-53 Start select [3] Logic OR All set-ups TRUE - Uint8
8-54 Reverse select [3] Logic OR All set-ups TRUE - Uint8
8-55 Set-up select [3] Logic OR All set-ups TRUE - Uint8
8-56 Preset reference select [3] Logic OR All set-ups TRUE - Uint8
8-9* Bus jog
8-90 Bus Jog 1 Speed 100 RPM All set-ups TRUE 67 Uint16
8-91 Bus Jog 2 Speed 200 RPM All set-ups TRUE 67 Uint16
*
default setting ()display text []value for use in communication via serial c ommunication port
228
MG.33.B
3.22 - VLT is a registered Danfoss trademark
