Danfoss ERC 213 Quick Start Guide

© Danfoss | DCS (im) | 2017.08
Quick Start Guide, ERC 213
2 | 520H12295 | DKRCE.PD.RL0.A1.02
Technical data
App Selection Select application based on application and
wiring conguration (i.e., refrigeration vs.
freezing, and number of temperature sensors).
The Typical Wiring Congurations diagram on
the reverse side of this document may be used
to assist with selection. All parameters can be
modied using the full menu. Some parameters
have min and max set points which may need to
be changed for less common congurations.
STEP Action Screen Display
STEP 1 Wire control, to include power and sensors
STEP 2
Power up control
Energize control
Control turns on, goes through start up, then
shows the current temperature reading
STEP 3
Enter Quick Conguration Menu and Select app
Press ”<” for more than three seconds within one minute
of power up to enter Quick Conguration Menu.
o61 appears on screen
Press “set” while o61 is on screen AP0 ashes on screen
Select appropriate app using App Selection section
below by pressing “ ” or “ ”, then press “set”.
o06 appears on screen
STEP 4
Select Sensor
Press “set” while o06 is on screen n10 ashes on screen
If using included sensor, leave default value “n10”. If using
another sensor, select using Sensor Resistance section
below or cycle through steps 2 – 4 changing the sensor
type until the temperature reading on the main screen
is accurate. As above, cycle between options by pressing
“ ” or “ ” and press “set” to save.
o06 appears on screen, then control resets
STEP 5
Set Temperature
From main screen, quickly press “set” (1 second). Current temp. setting appears on screen
Cycle to intended temperature by pressing “ ” or “ ” and
press “set” to save.
Screen returns to main screen
Quick Set-up
Control
Application
Code
Application
Defrost
Type*)
Defrost
Termination
Sensors
Default
Temp. [°F]
[r00]
Temp. Range
min. / max.
[°F]
[r02/r03]
Default
Dif. [°F]
[r01]
Defrost
Interval
[hrs]
[d03]
Max.
Defrost
Time [mins]
[d04]
Defrost
Termination
Temp. [°F]
[d02]
AP0 (Default) No preset application - full menu 2 36 -31 / 22 4 6 30 43
AP1 Refrigeration Natural Time 1 39 36 / 43 4 4 30 –
AP2 Refrigeration Electric Time 1 36 32 / 39 4 6 15 –
AP3 Freezing Electric Time 1 -11 -15 / -4 4 6 15 –
AP4 Refrigeration Electric Temp. 2 36 32 / 39 4 6 30 43
AP5 Freezing Electric Temp. 2 -11 -15 / -4 4 6 30 43
AP6 No preset application - simplied menu 2 36 -31 – 122 4 6 30 43
*) Hot gas defrost is an option available in full menu (d01).

Danfoss ERC 213 Specifications

General

Supply Voltage	230 V AC
Dimensions	75 x 33 x 85 mm
Digital Inputs	2
Enclosure Rating	IP20
Input Voltage	230 V AC
Housing Material	Plastic
Application	Refrigeration
Storage Temperature	-20 - 70 °C
Relative Humidity	20% to 80% non-condensing
Protection Class	Class II
Weight	0.2 kg
Operating Temperature	-10°C to +50°C
Power Consumption	3 W
