Danfoss EtherNet/IP Midi Drive FC 280 User Manual

12-22 Process Data Cong Read
Option: Function:
[1685] FC Port CTW 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1697] Alarm Word 3
[3421] PCD 1 Read For Application
[3422] PCD 2 Read For Application
[3423] PCD 3 Read For Application
[3424] PCD 4 Read For Application
[3425] PCD 5 Read For Application
[3426] PCD 6 Read For Application
[3427] PCD 7 Read For Application
[3428] PCD 8 Read For Application
[3429] PCD 9 Read For Application
[3430] PCD 10 Read For Application
[3450] Actual Position
[3456] Track Error
12-28 Store Data Values
Option: Function:
[0] * O The store function is inactive.
[2] Store all setups All parameter values in all set-ups are
stored in the non-volatile memory.
12-29 Store Always
Option: Function:
[0] * O Deactivate the function which always stores received
parameter data in non-volatile memory (EEPROM).
[1] On Activate the function which always stores received
parameter data in non-volatile memory (EEPROM).
5.2.4 12-3* EtherNet/IP
12-30 Warning Parameter
Range: Function:
0* [0 -
65535]
Read-only. Show the EtherNet/IP specic 16-bit
status word.
Bit Description
0 Owned
1 Not used
2 Congured
3 Not used
4 Not used
5 Not used
6 Not used
7 Not used
8 Minor recoverable fault
9 Minor unrecoverable fault
10 Major recoverable fault
11 Major unrecoverable fault
12 Not used
13 Not used
14 Not used
15 Not used
Table 5.1 Bit Description
12-31 Net Reference
Show the reference source in Instance 21/71.
Option: Function:
[0] * O Reference from the network is not active.
[1] On Reference from the network is active.
12-32 Net Control
Show the control source in Instance 21/71.
Option: Function:
[0] * O Control via the network is not active.
[1] On Control via the network is active.
12-33 CIP Revision
Range: Function:
Size related* [0 - 65535] Show the CIP revision of the option
software.
12-34 CIP Product Code
Range: Function:
Size related* [0 - 65535] Show the CIP product code.
12-35 EDS Parameter
Range: Function:
0* [0 - 0] Congure the frequency converter via device net
and build the EDS-le.
Parameters EtherNet/IP
28 Danfoss A/S © 06/2016 All rights reserved. MG07H102
