16-36 Inv. Nom. Current
Range: Function:
Application
dependent
*
[0.01 -
10000.00 A]
View the inverter nominal
current, which should match the
nameplate data on the
connected motor. The data are
used for calculation of torque,
motor protection, etc.
16-37 Inv. Max. Current
Range: Function:
Application
dependent
*
[0.01 -
10000.00 A]
View the inverter maximum
current, which should match the
nameplate data on the
connected motor. The data are
used for calculation of torque,
motor protection, etc.
16-38 SL Controller State
Range: Function:
0
*
[0 - 100 ] View the state of the event under execution by the
SL controller.
16-39 Control Card Temp.
Range: Function:
0 C
*
[0 - 100 C] View the temperature on the control card,
stated in °C.
16-40 Logging Buffer Full
Option: Function:
View whether the logging buffer is full (see parameter
group 15-1*). The logging buffer will never be full when
15-13 Logging Mode is set to Log always [0].
[0]
*
No
[1] Yes
16-49 Current Fault Source
Range: Function:
0
*
[0 - 8 ] Value indicates source of current faults including
short circuit, overcurrent, and phase imbalance (from
left):
1-4 Inverter
5-8 Rectifier
0 No fault recorded
3.17.4 16-5* Ref. & Feedb.
16-50 External Reference
Range: Function:
0.0
*
[-200.0 - 200.0 ] View the total reference, the sum of digital,
analog, preset, bus and freeze references,
plus catch-up and slow-down.
16-51 Pulse Reference
Range: Function:
0.0
*
[-200.0 - 200.0 ] View the reference value from programmed
digital input(s). The readout can also reflect
the impulses from an incremental encoder.
16-52 Feedback [Unit]
Range: Function:
0.000 Reference-
FeedbackUnit
*
[-999999.999 -
999999.999
ReferenceFeed-
backUnit]
View the feedback unit
resulting from the
selection of unit and
scaling in 3-00 Reference
Range, 3-01 Reference/
Feedback Unit,
3-02 Minimum Reference
and 3-03 Maximum
Reference.
16-53 Digi Pot Reference
Range: Function:
0.00
*
[-200.00 - 200.00 ] View the contribution of the digital
potentiometer to the actual reference.
16-57 Feedback [RPM]
Range: Function:
0 RPM
*
[-30000 -
30000 RPM]
Readout parameter where the actual
motor RPM from the feedback source can
be read in both closed-loop and open-
loop. The feedback source is selected by
par. 7-00.
Parameter Descriptions FC 300 Programming Guide
3-134 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
