15-10 Logging Source
Array [4]
Option: Function:
[1651] Pulse Reference
[1652] Feedback [Unit]
[1657] Feedback [RPM]
[1660] Digital Input
[1662] Analog Input 53
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status Word
[1860] Digital Input 2
[3110] Bypass Status Word
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
15-11 Logging Interval
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the interval in
milliseconds between each
sampling of the variables to
be logged.
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a window
is applied to freeze the log. The log will then retain a specified
percentage of samples before the occurrence of the trigger event
(15-14 Samples Before Trigger).
Option: Function:
[0] * FALSE
[1] TRUE
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a window
is applied to freeze the log. The log will then retain a specified
percentage of samples before the occurrence of the trigger event
(15-14 Samples Before Trigger).
Option: Function:
[16] Thermal warning
[17] Mains out of range
[18] Reverse
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
15-13 Logging Mode
Option: Function:
[0] * Log always Select Log always [0] for continuous
logging.
[1] Log once on
trigger
Select Log once on trigger [1] to
conditionally start and stop logging using
15-12 Trigger Event and 15-14 Samples Before
Trigger.
15-14 Samples Before Trigger
Range: Function:
50 * [0 - 100 ] Enter the percentage of all samples prior to a
trigger event which are to be retained in the log.
See also 15-12 Trigger Event and 15-13 Logging
Mode.
Parameter Descriptions FC 300 Programming Guide
3-128 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
3
