3.18.3 17-5* Resolver Interface
Par. group 17-5* is used for setting parameters for the MCB
103 Resolver Option.
Usually the resolver feedback is used as motor feedback from
permanent magnet motors with 1-01 Motor Control Principle
set to Flux with motor feedback.
Resolver parameters cannot be adjusted while the motor is
running.
17-50 Poles
Range: Function:
2
*
[2 - 2 ] Set the number of poles on the resolver.
The value is stated in the data sheet for resolvers.
17-51 Input Voltage
Range: Function:
7.0 V
*
[2.0 - 8.0 V] Set the input voltage to the resolver. The
voltage is stated as an RMS value.
The value is stated in the data sheet for
resolvers.
17-52 Input Frequency
Range: Function:
10.0 kHz
*
[2.0 - 15.0 kHz] Set the input frequency to the resolver.
The value is stated in the data sheet for
resolvers.
17-53 Transformation Ratio
Range: Function:
0.5
*
[0.1 - 1.1 ] Set the transformation ratio for the resolver.
The transformation ration is:
T
ratio
=
V
Out
V
In
The value is stated in the data sheet for
resolvers.
17-56 Encoder Sim. Resolution
Set the resolution and activate the encoder emulation function
(generation of encoder signals from the measured position from a
resolver). Needed when necessary to transfer the speed or position
information from one drive to another. To disable the function,
select [0].
Option: Function:
[0]
*
Disabled
[1] 512
[2] 1024
[3] 2048
[4] 4096
17-59 Resolver Interface
Activate the MCB 103 resolver option when the resolver
parameters are selected.
To avoid damage to resolvers, 17-50 Poles – 17-53 Transformation
Ratio must be adjusted before activating this parameter.
Option: Function:
[0]
*
Disabled
[1] Enabled
3.18.4 17-6* Monitoring and App.
This par. group is for selecting additional functions when
MCB 102 Encoder option or MCB 103 Resolver option is fitted
into option slot B as speed feedback.
Monitoring and application parameters cannot be adjusted
while the motor is running.
17-60 Feedback Direction
Change the detected encoder rotation direction without changing
the wiring to the encoder.
This parameter cannot be adjusted while the motor is running.
Option: Function:
[0]
*
Clockwise
[1] Counterclockwise
17-61 Feedback Signal Monitoring
Select which reaction the adjustable frequency drive should take if
a faulty encoder signal is detected.
The encoder function in 17-61 Feedback Signal Monitoring is an
electrical check of the hardware circuit in the encoder system.
Option: Function:
[0] Disabled
[1]
*
Warning
[2] Trip
[3] Jog
[4] Freeze Output
[5] Max Speed
[6] Switch to Open Loop
[7] Select Set-up 1
[8] Select Set-up 2
[9] Select Set-up 3
[10] Select Set-up 4
[11] stop & trip
Parameter Descriptions FC 300 Programming Guide
MG.33.MA.22 - VLT
®
is a registered Danfoss trademark 3-139
3
