3.21.5 35-4* Analog Input X48/2 (MCB 114)
35-42 Term. X48/2 Low Current
Range: Function:
4.00
mA
*
[Application
dependant]
Enter the current (mA) that
corresponds to the low reference
value, set in par. 35-44. The value
must be set at > 2 mA in order to
activate the Live Zero Timeout
Function in par. 6-01.
35-43 Term. X48/2 High Current
Range: Function:
20.00 mA * [Application
dependant]
Enter the current (mA) that
corresponds to the high
reference value (set in par.
35-45).
35-44 Term. X48/2 Low Ref./Feedb. Value
Range: Function:
0.000 * [-999999.999 -
999999.999 ]
Enter the reference or feedback
value (in RPM, Hz, bar, etc.) that
corresponds to the voltage or
current set in par. 35-42.
35-45 Term. X48/2 High Ref./Feedb. Value
Range: Function:
100.000 * [-999999.999 -
999999.999 ]
Enter the reference or feedback
value (in RPM, Hz, bar, etc.) that
corresponds to the voltage or
current set in par. 35-43.
35-46 Term. X48/2 Filter Time Constant
Range: Function:
0.001 s * [0.001 -
10.000 s]
Enter the filter time constant. This is a
first-order digital low pass filter time
constant for suppressing electrical noise
in terminal X48/2. A high time constant
value improves dampening but also
increases the time delay through the filter.
Parameter Descriptions FC 300 Programming Guide
3-146 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
3
