Danfoss FC 300 Series User Manual

35-17 Term. X48/4 High Temp. Limit
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the maximum
temperature reading that is
expected for normal
operation of the
temperature sensor at
terminal X48/4.
3.21.3 35-2* Temp. Input X48/7 (MCB 114)
35-24 Term. X48/7 Filter Time Constant
Range: Function:
0.001 s * [0.001 -
10.000 s]
Enter the filter time constant. This is a
first-order digital low pass filter time
constant for suppressing electrical noise
in terminal X48/7. A high time constant
value improves dampening but also
increases the time delay through the filter.
35-25 Term. X48/7 Temp. Monitor
This parameter gives the possibility of enabling or disabling the
temperature monitor for terminal X48/7. The temperature limits
can be set in par. 35-26 and 35-27.
Option: Function:
[0] * Disabled
[1] Enabled
35-26 Term. X48/7 Low Temp. Limit
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the minimum
temperature reading that is
expected for normal
operation of the
temperature sensor at
terminal X48/7.
35-27 Term. X48/7 High Temp. Limit
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the maximum
temperature reading that is
expected for normal
operation of the
temperature sensor at
terminal X48/7.
3.21.4 35-3* Temp. Input X48/10 (MCB 114)
35-34 Term. X48/10 Filter Time Constant
Range: Function:
0.001 s * [0.001 -
10.000 s]
Enter the filter time constant. This is a
first-order digital low pass filter time
constant for suppressing electrical noise
in terminal X48/10. A high time constant
value improves dampening but also
increases the time delay through the filter.
35-35 Term. X48/10 Temp. Monitor
This parameter gives the possibility of enabling or disabling the
temperature monitor for terminal X48/10. The temperature limits
can be set in pars. 35-36/37.
Option: Function:
[0] * Disabled
[1] Enabled
35-36 Term. X48/10 Low Temp. Limit
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the minimum
temperature reading that is
expected for normal
operation of the
temperature sensor at
terminal X48/10.
35-37 Term. X48/10 High Temp. Limit
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the maximum
temperature reading that is
expected for normal
operation of the
temperature sensor at
terminal X48/10.
Parameter Descriptions FC 300 Programming Guide
MG.33.MA.22 - VLT
®
is a registered Danfoss trademark 3-145
3
3
