Danfoss H1 078 - External Filter Replacement

4. Install the remaining snap-ring.
Shaft Assembly
J100
P106038
J150
J300
J250
J200
J200
Protective
cover
Seal
installation
tool
J150
J220
Seal Installation Tool
P106492
55 mm
[2.17 in]
120 mm
[4.72 in]
078/089/100
78 mm
[3.07 in]
82 mm
[3.23 in]
115/130
147/165
7 mm
[0.28 in]
51 mm
[2. in]
68.5 mm
[2.70 in]
50°
80°
44.7 mm
[1.76 in]
89.4 mm
[3.52 in]
7 mm
[0.276 in]
78 mm
[3.07 in]
75.6 mm
[2.97 in]
210/250
4.4 mm
[0.17 in]
80°
57.5 mm
[2.26 in]
89.4 mm
[3.52 in]
External Filter Replacement
Removal
1. With the prime mover off, hold the filter (T150) in place, and remove the plug (T015) using a 24 mm
wrench.
2. Remove the filter.
3. Remove and discard the seal (T045) and O-ring (T035).
Service Manual
H1 Pumps 069/078, 089/100, 115/130, 147/165, 210/250
Minor Repair
©
Danfoss | May 2018 520L0848 | AX00000087en-US0308 | 53
